Description
Parameter
| Model | GT-F450H |
| Machine Dimension(mm) | 2091x1484x1344 |
| Max Packing Size (mm)（L -∞） | Unlimited |
| Max Packing Size (mm)（W+H）H＜190 | 400 |
| Cross Bar Length (mm) | 520 |
| Max Film Width(mm) | 580 |
| Packing Capacity（ppm） | 10-50 |
| Power Source | 1Ph 220V 50/60Hz |
| Power(Kw) | 3 |
| Air Consumption (Ni/min) | 40(6-8bars) |
| Applicable Film | POF/PE |
Application
Suitable for products of various lengths.
Features
1.Sealing line can be positioned to the middle of the products.
2.Servo drive ensures the continuous and stable cutting and sealing of the transverse knife.
3.Equipped with anti-cutting and alarm function,and can be optionally fitted with close contact belts,color film positioning photoelectric,transparent photoelectric detection,and PE film sealing and cutting components.
4.Frequency converter controls the conveying,film feeding,film pulling and waste film collection,achieving high efficiency and perfect results.
5.Packaging speed up to 60 packs per minute.
