Description
Parameter
| Item | Specification |
|---|---|
| Model | GTS-D40 |
| Weighing Range | Up to 40 kg |
| Sorting Capacity | Up to 60 pcs/min |
| Conveyor Speed | Up to 45 m/min |
| Maximum Sorting Accuracy (3σ) | ±5 g |
| Display | 7-inch Monitor |
| Operation Mode | Touch Screen |
| Product Memory Capacity | Up to 100 Products |
| Body Height | 400–1200 mm (±50 mm) |
| Roller Center Distance | 600 mm / 800 mm / 1200 mm |
| Conveyor Belt Width | 400 mm / 500 mm / 600 mm |
| Power Supply | AC220V ±10%, Single Phase (Optional AC380V, Three-Phase), 50/60Hz, 300VA |
| Inrush Current | 20A (Typical, within 20 ms) |
| Machine Weight | 200 kg |
| Operating Temperature Range | 0°C to 40°C |
| Temperature Stability Requirement | Temperature variation should not exceed ±5°C/h to ensure weighing accuracy |
| Relative Humidity | 30%–85% RH, non-condensing |
| Protection Class | IP54 (IP65 Optional) |
| Housing Material | Painted Steel; Stainless Steel SUS304 Optional (except certain components) |
Application
Applicable for missing item detection of boxed/cased packaged products, weight detection of various large-size soft bag packages, widely used in food, pharmaceutical, logistics, daily chemical and other industries with large package weight inspection requirements.
Features
1. Equipped with high-load high-precision load cell, adapted to large package weight detection, with strong anti-interference ability and stable long-term weighing performance.
2. Built-in multi-functional detection mode, supporting both weight over/under sort and missing item inspection for large packages, meeting diversified production line needs.
3. Reinforced industrial conveyor structure design, durable and wear-resistant, suitable for long-term continuous operation in high-load production scenarios.
4. Equipped with intuitive HMI touch interface, supporting real-time production data statistics, fault self-diagnosis and parameter quick setting, easy to operate and maintain.
